Rugged Elevator Help Point JR301-SC
This Vandal Resist Emergency Telephone is based on a stainless steel faceplate and provide a clear hands free, loud-speaking operation for any public area. It is designed to meet the needs of clients who experience loss through vandalism.
Description
Model Number: JR301-SC
The Vandal Resist Emergency Telephone is based on a stainless steel faceplate and provide a clear handsfree, loud-speaking operation for any public area. It is designed to meet the needs of clients who experience loss through vandalism.
APPLICATIONS
vandalism.Ideal for Elevators/Lifts, Parking lots, Prisons, Railway/Metro platforms, Hospitals, Police stations, ATM machines, Stadiums, Shopping malls, Doors, Hotels, outside building etc.
MAIN FEATURES of Rugged Elevator Help Point
- Standard Analogue phone
- Robust housing, constructed of stainless steel, back-cover made of cold rolled steel with powder coated
- Vandal resistant metal button
- Hands free operation
- Programmable for speed-dialing (PPT)
- Can be programmed remotely by tone phone
- Non-volatile memory
- On wall mounting, simple installation
- Weather protection IP54-IP65
- 4 X Tamper proof screws for mounting
- Fast-fit terminal connection
- Telephone line powered
- CE, FCC, RoHS, ISO9001 compliant
TECHNICAL SPECIFICATIONS of Rugged Elevator Help Point
Analogue Version | |
Power Supply | From the analogue telephone network |
Supply Voltage | 24 VDC to 65 VDC |
Supply Current | 20 mA DC to 100 mA DC |
Ringer Volume | - 80dB(A) at a distance of 1 m |
Dialing Method | DTMF mode in accordance with ITU-T recommendation Q.23. |
Protection type | IP 66 as per EN60529 |
Operating temperature | -20°C to +70°C |
Storage temperature | -35°C to +85°C |
PACKAGE of Rugged Elevator Help Point
Unit size: 136*206*42 (mm)
Packaging materials: pearl cotton, carton
Net weight: 1.5 KG
CERTIFICATIONS
Hot Tags: Elevator Emergency Telephone, Railway applications Phone,Tunnels phone,Door phone, Industrial telephone, Prison phone, Jail phone, Parking lots help point, Hospitals help phone, Guard Stations phone, Police stations SOS call box, Bank halls help phone, ATM machines call box, Stadiums help point,Metro Help phone, Subway SOS Phone
