Moisture Proof Broadcasting Telephone JR104-SC-H

With metal material horn, this handsfree telephone can broadcast remotely for notification. The horn works after 1-9 rings (adjustable), shut when press the button or call finished. This Moisture Proof Broadcasting Telephone is fully contained within a corrosion resistant cast aluminium weatherproof case, which providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.

  Model Number: JR104-SC-H

With metal material horn, this handsfree telephone can broadcast remotely for notification. The horn works after 1-9 rings (adjustable), shut when press the button or call finished.

This Moisture Proof Broadcasting Telephone is fully contained within a corrosion resistant cast aluminium weatherproof case, which providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.


  MAIN FEATURES of Moisture Proof Broadcasting Telephone

Standard Analogue phone

- Also available in SIP/VoIP, or GSM/3G version

Aluminum alloy die-casting body

- Vandal resistant metal button


- Hands free operation

- One button for emergency call

- Wall/Pillar mounting, simple installation


- Inductive coupler fitted as standard for hard of hearing

- The phone will ringing loudly when there is a incoming call

- Built-in amplifier, with external ringer :15W (30W optional), for broadcasting feature


- Phone line powered (Analogue)

- External power supply or PoE (SIP)

- RJ45 Port for SIP connection

CE, FCC, RoHS, ISO9001 compliant


   APPLICATIONS of Moisture Proof Broadcasting Telephone

This Moisture Proof Broadcasting Telephone is very Popular For Tunnels, Mining, Marine, Undergrounds, Metro Stations, Railway Platform, Rail trackside, Highwayside, Parking Lots, Steel Plants, Chemical Plants, Power Plants And Related Heavy Duty Industrial indoor&outdoor Application, Etc.

waterproof telephone.jpg

   TECHNICAL SPECIFICATIONS of Moisture Proof Broadcasting Telephone

Analogue Version

Power Supply

From the analogue telephone network

Supply Voltage

24 VDC to 65 VDC

Supply Current

20 mA DC to 100 mA DC

Ringer Volume

- 80dB(A)  at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)

Dialing Method

DTMF mode in accordance with ITU-T recommendation Q.23.


SIP Version

Power Supply

PoE or 12V DC

Power Consumption

-Idle:1.5W
-Active:1.8W

SIP Protocol

SIP 2.0 (RFC3261)

Support Codec

G.711 A/U, G.722 8000/16000, G.723, G.729

Communication Type

Full duplex

Ringer volume

- 90~95dB(A)  at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)


Ambient conditions

Protection type

IP 66 as per EN60529

Operating temperature

-40°C to +70°C

Storage temperature

-45°C to +85°C

  CERTIFICATIONS

J&R Certifications.png


  OUR SERVICE

1. ODM & OEM products or solutions

2. Sample order is greatly welcomed.

3. We will reply your inquiry within 12 hours

4. Update the productive process and show the packing details

5. After delivered the goods, we will track the products for you once every two days, until you get the products. When you got the products, if there is any further questions, welcome to contact us and we will solve the problems for you in time.

Management System.jpg


   PACKAGE of Moisture Proof Broadcasting Telephone

Unit size: 204 *334 *109 (mm)

Carton size: 200 *300 *440 (mm)

Packaging materials: pearl cotton, carton

Gross weight: 6 KG

Net weight: 5 KG



  SHIPMENT of Weatherproof Heavy duty industrial telephone




J&R Technology is one of the leading China moisture proof broadcasting telephone jr104-sc-h manufacturers and suppliers with one of the famous brands, we also have our own factory, we are a professional company and can offer you best moisture proof broadcasting telephone jr104-sc-h products. Welcome to buy high-quality products from us.
Hot Tags: moisture proof broadcasting telephone jr104-sc-h, China, manufacturers, suppliers, factory, company, brands, buy, best, high-quality, products
