Courtesy Telephones JR205-FK

Courtesy Telephones JR205-FK housed in stainless steel box and manufactured to a high standard, it offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times. It is extremely easy to install. The cable entrance is on the back of the phone to prevent from artificial damage, while the keypad is weather and vandal resistant.

  Model Number:JR205-FK

Housed in stainless steel box and  manufactured to a high standard, these telephones offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times.

Extremely easy to install. The cable entrance is on the back of the phone to prevent from artificial damage, while the keypad is weather and vandal resistant.


   FEATURES of Courtesy Telephones
1. Standard Analogue/ SIP/ GSM/ 3G Phone
2. Can be programmed remotely by tone phone or locally via keypad
3. Robust housing, constructed of stainless steel
4. Handset operation
5. Weatherproof and corrosion resisitant handset
6. Mini Size, on wall mounting, simple intallation
7. Weather proof protection IP54-IP65
8. Inductive coupler fitted as standard for hard of hearing
9. Tamper resistant fixings
10. Fast-fit terminal connection
11. Full Rugged & Durable keypad (16keys),easy to operate
12. Non-volatile memory
13. Stainless steel armoured handset cord
14. Four additional buttons programmable for speed dial
15. Inductive coupler fitted as standard for hard of hearing
16. CE, FCC, RoHS, ISO9001 compliant


   APPLICATIONS of Courtesy Telephones JR205-FK

The Handset Telephone is designed to meet the needs of client who experience loss through vandalism.

Ideal for parking lots, prisons, railway/metro platforms, hospitals, police stations, ATM machines, stadiums, outside building etc.

anti-vandal handset phone.png


  TECHNICAL SPECIFICATIONS

Casing Material: Stainless steel body

Handset Material: ABS material handset with stainless steel spiral cord.

Keypad: Weather sealed tactile digital keypad.Chrome key and frame made of zinc alloy.Vandal resistance.

Weather Resistance: IP55

Ringing Tone: Shrill warble tone 80 dBA @ 1 metre typical

Hook switch: Electronic / magnetic with no visible moving parts

M.T.B.F.: Calculated to have an M.T.B.F. in excess of 50,000 hours using

Weight: Up to 4 kg depending on option

Analogue Version

Power Supply

From the analogue telephone network

Supply Voltage

24 VDC to 65 VDC

Supply Current

20 mA DC to 100 mA DC

Ringer Volume

- 80dB(A)  at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)

Dialing Method

DTMF mode in accordance with ITU-T recommendation Q.23.

SIP Version

Power Supply

PoE or 12V DC

Power Consumption

-Idle:1.5W
-Active:1.8W

SIP Protocol

SIP 2.0 (RFC3261)

Support Codec

G.711 A/U, G.722 8000/16000, G.723, G.729

Communication Type

Full duplex

Ringer volume

- 90~95dB(A)  at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)

3G Version

Power Supply

12V DC

Power Consumption

-Idle:0.3W
-Active: 1.5W

Communication Type

Full duplex

Ringer volume

90~95dB(A)  at a distance of 1 m

Program Method

Remote programming by SMS

Frequency

 A version:

- Dual-Band WCDMA/HSDPA 850/1900MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

E version:

- Dual-Band UMTS/HSDPA 900/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

J version:

- Dual-Band UMTS/HSDPA 850(800)/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

Ambient conditions

Protection type

IP 66 as per EN60529

Operating temperature

-25°C to +70°C

Storage temperature

-35°C to +85°C


  PACKAGE of Courtesy Telephones JR205-FK

Unit size: 300 *120 *101 (mm)

Carton size: 340 *235 *165 (mm )

Packaging materials: Pearl cotton, Carton

Net weight: 3.5 KG

Gross weight: 4 KG


  DIMENSIONS of Courtesy Telephones JR205-FK

(Measured in mm)


JR205-FK.png    JR205-FK..png



  Certifications

JR200 Certifications.png
